Create Mechanical Extruder

Create Mechanical Extruder

A mechanical extruder block. Can be used to generate any block or item from adjacent blocks/fluids. This mod it's meant to be used in modpacks.

Heavily inspired on Thermal Expansions Igneous Extruder.

Dedicated wiki

1.21.1-2.x Version Requires Mechanicals Lib

• Curseforge

Version support & documentation

• 1.21.1: Supported. Documentation refers to this version.
• 1.20.1: Only critical issues
• 1.19.x: Unsupported: Documentation
• 1.18.x: Unsupported: Documentation

Andesite Extruder

• Kinetic block.
• Filter functionality for selecting output when recipe collides.
• Shift+right click with empty hand to extract content.
• Extraction via automation.

Brass Extruder

• Can consume source blocks.

Extruding recipes

• JEI integration.
• Per recipe custom requirements.

BlockState

Block

{
        "blocks": "minecraft:water"
},

Block with State

{
  "blocks": "minecraft:furnace",
  "state": {
    "lit": "true"
  }
}

Input BlockStates

"blockIngredients": {
    "first": {
        "blocks": "minecraft:water"
    },
    "second": {
        "blocks": "minecraft:lava"
    }
}

Catalyst BlockStates

"catalyst": {
  "blocks": "minecraft:obsidian"
}

Required bonks (optional)

• "requiredBonks": 10
• Defines how many times must hit.

Advanced extruder (brass) per recipe (optional)

• "advanced":"true"
• Recipes requires brass extruder.

Consume blocks (advanced recipe)

• Advanced extruder can consume blocks.

"consumeBlocks": {
    "first": false,
    "second": true
},

Recipe Requirements

• MinY/MaxY

"requirements": [
    {
        "type": "mechanicals:min_y",
        "value": 0
    },
    {
        "type": "mechanicals:max_y",
        "value": 60
    }
],

• MinSpeed/MaxSpeed

"requirements": [
    {
        "type": "mechanicals:max_speed",
        "value": 4.0
    }
],

• Biome

"requirements": [
    {
        "type": "mechanicals:biome",
        "value": "minecraft:plains"
    }
],

• BiomeTag

"requirements": [
    {
        "type": "mechanicals:biome_tag",
        "value": "minecraft:is_nether"
    }
],

KubeJS

• Remove al Extruding recipes.

ServerEvents.recipes(event => {
  event.remove({ type: 'create_mechanical_extruder:extruding' })
})

• Chanced output (binding)

Output.of('minecraft:clay', 0.5)
Output.of('4xminecraft:clay', 0.5)

• BlockPredicate (binding)

BlockPredicate.of('minecraft:sand')

• RecipeRequirement (binding)

RecipeRequirement.minY(int) //ex: RecipeRequirement.minY(-10)
RecipeRequirement.maxY(int) //ex: RecipeRequirement.maxY(20)
RecipeRequirement.minSpeed(float) //ex: RecipeRequirement.minSpeed(2.0)
RecipeRequirement.maxSpeed(float) //ex: RecipeRequirement.maxSpeed(160)
RecipeRequirement.biome(string) //ex: RecipeRequirement.biome("minecraft:plains")
RecipeRequirement.maxSpeed(string)  //ex: RecipeRequirement.biome("minecraft:plains")

• Add recipes

ServerEvents.recipes(event => {
  /**
    create_mechanical_extruder.extruding(Output result, BlockPredicate[] inputs)
    .catalys(BlockPredicate catalyst) // optional, default: empty
    .advanced(true) //optional, default: false
    .consumeBlock(Couple consume) //optional, default: empty
  **/

    event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:dirt'),[BlockPredicate.of('minecraft:lava'),BlockPredicate.of('minecraft:stone')])
            .catalyst('minecraft:clay')})

• Some examples:

//Minimal
        event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:redstone_block'),[BlockPredicate.of('minecraft:lava'),BlockPredicate.of('minecraft:stone')])

        //Catalyst
        event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:dirt'),[BlockPredicate.of('minecraft:lava'),BlockPredicate.of('minecraft:stone')])
            .catalyst('minecraft:clay')

        //Bonks
        event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:sand'),[BlockPredicate.of('minecraft:lava'),BlockPredicate.of('minecraft:stone')])
            .requiredBonks(10)

        //Chanced output
        event.recipes.create_mechanical_extruder.extruding(Output.of('minecraft:red_sand',0.5),[BlockPredicate.of('minecraft:lava'),BlockPredicate.of('minecraft:stone')])

        //Chanced output & bonks
        event.recipes.create_mechanical_extruder.extruding(Output.of('minecraft:birch_planks',0.5),[BlockPredicate.of('minecraft:lava'),BlockPredicate.of('minecraft:stone')])
            .requiredBonks(5)

        //Advanced extruder
        event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:obsidian'),[BlockPredicate.of('minecraft:sand'),BlockPredicate.of('minecraft:gravel')])
            .catalyst(BlockPredicate.of("minecraft:dirt"))
            .advanced(true)

        //Advanced extruder + consume blocks
        event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:birch_planks'),[BlockPredicate.of('minecraft:sand'),BlockPredicate.of('minecraft:gravel')])
            .catalyst(BlockPredicate.of("minecraft:dirt"))
            .consumeBlocks(true)
            .advanced(true)

        //Advanced extruder + consume different blocks
        event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:obsidian'),[BlockPredicate.of('minecraft:sand'),BlockPredicate.of('minecraft:gravel')])
            .catalyst(BlockPredicate.of("minecraft:dirt"))
            .consumeBlocks([true,false])
            .advanced(true)

        //Biome requirement
        event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:iron_block'),[BlockPredicate.of('minecraft:sand'),BlockPredicate.of('minecraft:gravel')]).catalyst(BlockPredicate.of("minecraft:dirt"))
            .requirements(
                [
                    RecipeRequirement.biome("minecraft:plains")
                ]
            );

        //Biome Tag requirement
        event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:gold_block'),[BlockPredicate.of('minecraft:sand'),BlockPredicate.of('minecraft:gravel')]).catalyst(BlockPredicate.of("minecraft:dirt"))
            .requirements(
                [
                    RecipeRequirement.biomeTag("minecraft:is_nether")
                ]
            );

        //MinY & MaxY requirement
        event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:coal_block'),[BlockPredicate.of('minecraft:sand'),BlockPredicate.of('minecraft:gravel')]).catalyst(BlockPredicate.of("minecraft:dirt"))
            .requirements(
                [
                    RecipeRequirement.minY(-10),
                    RecipeRequirement.maxY(12),
                ]
            );
        //MinSpeed & MaxSpeed requirement
        event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:dirt'),[BlockPredicate.of('minecraft:sand'),BlockPredicate.of('minecraft:gravel')]).catalyst(BlockPredicate.of("minecraft:dirt"))
            .requirements(
                [
                    RecipeRequirement.minSpeed(1.0),
                    RecipeRequirement.maxSpeed(16.0),
                ]
            );

        //All requirements together
        event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:emerald_block'),[BlockPredicate.of('minecraft:sand'),BlockPredicate.of('minecraft:gravel')]).catalyst(BlockPredicate.of("minecraft:dirt"))
        .requirements(
            [
                RecipeRequirement.minSpeed(6.0),
                RecipeRequirement.maxSpeed(16.0),
                RecipeRequirement.minY(10),
                RecipeRequirement.maxY(12),
                RecipeRequirement.biomeTag("minecraft:is_nether")

            ]
        );

        //Everything together
        event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:emerald_block'),[BlockPredicate.of('minecraft:sand'),BlockPredicate.of('minecraft:gravel')])
        .catalyst(BlockPredicate.of("minecraft:dirt"))
        .advanced(true)
        .consumeBlocks(true)
        .requirements(
            [
                RecipeRequirement.minSpeed(16.0),
                RecipeRequirement.minY(10),
                RecipeRequirement.maxY(12),
                RecipeRequirement.biomeTag("minecraft:is_nether")

            ]
        );

        // Funny things
        // Flower pots
        event.recipes.create_mechanical_extruder.extruding(Item.of('minecraft:glowstone'),[BlockPredicate.of('minecraft:potted_dandelion'),BlockPredicate.of('minecraft:potted_poppy')])

Thanks to the Creators of Create.

Code inspiration from the Create mod itself.
